1000V Ticarət və Sənaye Enerji Anbar Sistemi

1000V Ticarət və Sənaye Enerji Anbar Sistemi

Ödəniş növü:	T/T
Incoterm:	EXW
Min. Sifariş:	1 Set/Sets
Nəqliyyat:	Ocean,Land,Air,Express
Port:	shenzhen
application:	Hybrid Solar System Off-grid Solar System On-grid Solar System

Contact Now

Məhsul xüsusiyyətləri
Qablaşdırma və Çatdırılma
Məhsul Təsviri
Təchizat bacarığı və əlavə məlum...

Məhsul xüsusiyyətləri

Model nömrəsi: EAPCS50K-113kWh

Marka: Bosinə

Place Of Origin: China

Output Type: Multiple

Types Of: Dc/Ac Inverters

Battery Core Type: 3.2V/37Ah

System Battery Configuration: 4P240S

Battery Rated Capacity: 113.66kWh

Battery Voltage Range: 648~864V

AC Side Rated Power: 50kW

AC Cari Harmonik Təhrif Dərəcəsi: <3% (qiymətləndirilmiş güc)

DC Component: <0.5%(rated power)

Grid Voltage Range: -15%~10%

Power Factor: >0.99(rated power)

Isolation Method: Non-isolation

Qablaşdırma və Çatdırılma

Satış vahidləri:	Set/Sets
Paket növü:	Taxta qutu

The file is encrypted. Please fill in the following information to continue accessing it

Məhsul Təsviri

Model	EAPCS50K-113kWh	EAPCS50K-215kWh	EAPCS100K-215kWh
Battery
Battery core type	3.2V/37Ah	3.2V/280Ah	3.2V/280Ah
System battery configuration	4P240S	1P240S	1P240S
Battery rated capacity	113.66kWh	215.04kWh	215.04kWh
Battery voltage range	648~864V	648~864V	648~864V
AC Side
AC side rated power	50kW	50kW	100kW
AC current harmonic distortion rate	<3%(rated power)	<3%(rated power)	<3% (rated power)
DC component	<0.5%(rated power)	<0.5%(rated power)	<0.5%(rated power)
AC side rated voltage	380V	380V	380V
Grid voltage range	-15%~10%	-15%~10%	-15%~10%
Power factor	>0.99(rated power)	>0.99(rated power)	>0.99(rated power)
Reactive power adjustable range	-105%~105%	-105%~105%	-105%~105%
Rated grid frequency	50Hz	50Hz	50Hz
Grid frequency range	45~55Hz	45~55Hz	45~55Hz
Isolation method	Non-isolation	Non-isolation	Non-isolation
System
Dimensions(WxHxD)	1500x2000x1360mm	1400x2300x1560mm	1400x2300x1560mm
Weight	2000kg	2660kg	2700kg
IP rating	IP54	IP54	IP54
Operation temperature range	-25~55°C	-25~55°C	-25~55°C
Operation humidity range	0~95%(non-condensing)	0~95%(non-condensing)	0~95%(non-condensing)
Altitude	≤2000m	≤2000m	≤2000m
Battery temperature control method	Air conditioning cooling	Air conditioning cooling	Air conditioning cooling
Converter cooling method	Intelligent air cooling	Intelligent air cooling	Intelligent air cooling
Fire-fighting system	Aerosol firefighting, water firefighting	Aerosol firefighting, water firefighting	Aerosol firefighting, water firefighting
System communication interface	Ethernet
External system communication protocol	Modbus-TCP
